Industrial Gate Valve

Lug Butterfly Valve Manufacturer

As a leading Lug Butterfly Valve Manufacturer, we specialize in providing durable and precision-engineered valves designed for efficient flow control and shut-off in industrial and commercial applications. The Lug Type Butterfly Valve features a robust body with threaded lugs, allowing it to be installed between flanges using bolts without the need for nuts — making it ideal for end-of-line service or systems requiring frequent maintenance.

Our valves are manufactured using high-grade materials such as cast iron, ductile iron, carbon steel, and stainless steel, ensuring exceptional corrosion resistance, smooth operation, and long service life. Each valve is designed to deliver tight sealing performance under varying pressure and temperature conditions, suitable for water supply, wastewater treatment, chemical processing, HVAC, and power plants.

Key Features

• Type: Lug Type Butterfly Valve

• Size Range: 40mm to 600mm (1½” to 24”)

• Body Material: Cast Iron / Ductile Iron / Stainless Steel / Carbon Steel

• Disc Material: SS 304 / SS 316 / DI / Aluminum Bronze

• Seat Material: EPDM / Nitrile / Viton / PTFE

• End Connection: Lug Type (Fits Between Flanges)

• Pressure Rating: PN10 / PN16 / ANSI Class 150

• Temperature Range: Up to 120°C

• Operation: Lever, Gear, Pneumatic, or Electric Actuator

• Design Standard: API / BS / IS / DIN

• Applications: HVAC Systems, Water Distribution, Chemical Industries, Fire Fighting Systems, and General Industrial Pipelines
