Sant Make Motorized Buttterfly Valves

Sant Motorized Butterfly Valve

The Sant Motorized Butterfly Valve is a high-performance flow control solution designed for precise and automatic regulation of fluids in pipelines. Equipped with a reliable electric actuator, this valve enables smooth, efficient, and remote-controlled operation—ideal for automation in water treatment plants, HVAC systems, fire-fighting networks, and industrial process lines.

Manufactured from premium-grade cast iron, ductile iron, or stainless steel, the Sant Motorized Butterfly Valve ensures excellent durability, corrosion resistance, and leak-proof performance under various operating conditions. Its wafer or lug-type body design offers compactness and easy installation between flanges, while the actuator provides quick response and low maintenance operation.

Key Features:

• Type: Motorized Butterfly Valve (Electric Actuated)

• Brand: Sant

• Size Range: 40mm to 600mm (larger sizes available on request)

• Body Material: Cast Iron / Ductile Iron / Stainless Steel

• Disc Material: SS 304 / SS 316 / Ductile Iron with Epoxy Coating

• Seat Material: EPDM / NBR / PTFE

• Pressure Rating: PN10 / PN16

• Operation: Electric Actuator (On/Off or Modulating Type)

• Power Supply: 230V AC / 24V DC / 415V AC (as per model)

• Temperature Range: Up to 120°C

• End Connection: Wafer / Lug Type

• Application: HVAC Systems, Water Supply, Fire Fighting, Process Automation, and Industrial Fluid Control
